Grooved Y-strainer
1) Size: DN65-DN2002) Nominal Pressure: 1.6MPa3) Sealing Test Pressure: 1.76MPa4) Shell Test Pressure: 2.4MPa5) Applicable Temperature: 0~80℃6) Fluid Medium: Water7) Material: DI Body Epoxy Resin Coated Red, Stainless Steel Mesh, Steel Nut.8) Connecting Diameter(2.5"-8"): (73 , 76.1)(88.9)(108 , 114.3)(133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)
Swing Check Valve / Non-Return Valve
1) Size: DN50-DN2002) Nominal Pressure: 1.6MPa3) Testing Pressure: 1.8MPa4) Applicable Temperature: 0~80℃5) Fluid Medium: Water6) Material: DI Body Epoxy Resin Coated Red or Blue, DI Disc Cover With NBR7) Flange Holes Match To: BS4504 / EN1092 / DIN2502
Grooved Swing Check Valve
1) Size: DN50-DN2002) Nominal Pressure: 1.6MPa3) Testing Pressure: 1.8MPa4) Applicable Temperature: 0~80℃5) Fluid Medium: Water6) Material: DI Body Epoxy Resin Coated Red, DI Disc Rubber Coated, Steel Nut.7) Connecting Diameter(2"-8"): (60.3)(73 , 76.1)(88.9)(108 , 114.3)(133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)
OS&Y Gate Valve With Tamper Switch, Groove Connection
1) Size: DN50-DN3002) Nominal Pressure: 1.6MPa3) Sealing Test Pressure: 1.76MPa4) Shell Test Pressure: 2.4MPa5) Applicable Temperature: 0~80℃6) Fluid Medium: Water7) Material: ductile cast iron body, 2cr13 stem, NBR + DI wedge, ductile cast iron handwheel8) Connecting Diameter(DN50-DN300): (60.3)(73 , 76.1)(88.9)(108 , 114.3) (133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)(273)(323.9)
OS&Y Gate Valve, Groove Connection
1) Size: DN50-DN3002) Nominal Pressure: 1.6MPa3) Sealing Test Pressure: 1.6MPa4) Shell Test Pressure: 2.0MPa5) Applicable Temperature: 0~80℃6) Fluid Medium: Water7) Material: ductile cast iron body, DI rotating nut, 2cr13 stem, NBR + DI wedge, ductile cast iron handwheel8) Connecting Diameter(DN50-DN300): (60.3)(73 , 76.1)(88.9)(108 , 114.3) (133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)(273)(323.9)
